4-channel amplifier with small dimensions MICRO SIZE แอมป์ไซด์จิ๋ว ที่อัดแน่นด้วยคุณภาพ กับ #GROUNDZERO GZCS A-4.80

GZPC 165SQ 165 mm / 6.5″ 2-way component speaker system Description 250 Watts max 6.5″ high end 2-way component speaker system with aluminum cast basket including 1.1″ silk dome tweeters 2-way component speaker Made in Germany Alumium-ceramics cone Conex spider Solid aluminum cast basket Universal 4 ohms version GZPT 28SX High end 18 dB/oct and 12 dB/oct crossover 1 kit / package Additional Information Model 2-way component speakers Diameter 165 mm / 6.5" Belastbarkeit (RMS/max.) 150 / 250 Watts Impedanz 4 Ohms Effizienz 90 dB Frequency Response 30 Hz – 30 kHz Tweeter GZPT 28SX Midwoofer GZPK 16SQ Mounting Ø 143.5 mm Einbautiefe 68 mm Crossover GZPX 165SQ Crossover frequency 2800 Hz

" Ground Zero GZPC 40 SQ ลำโพง 2 ทาง Full Range นวัตกรรมใหม่ล่าสุด " ทั้งชุดประกอบไปด้วย 6.5″ high end 2-way component speaker system with aluminum cast basket including 1.6″ full range GZPK 16SQ Made in Germany Alumium-ceramics cone Conex spider Solid aluminum cast basket Universal 4 ohms version GZPF 40SQ 1.6″ high end full range speaker with aluminum cone 40 mm / 1.6″ high end full range speaker Made in Germany Anodized aluminum cone Aluminum cast housing Neodymium motor Gold plated soldering terminal

ชุดลำโพง Ground Zero Reference 3 ทาง Gold Edition Limited งาน Handmade Germany ทั้งชุดประกอบไปด้วย 1. GZPT Reference 28 Gold Edition (Tweeter) GZPT Reference 28 Gold Edition 28 mm / 1.1″ high end tweeter – Gold Edition 150 Watts max 1.1″ high end silk dome tweeter with CNC turned and gold plated aluminum housing 25 mm / 1″ high end tweeter Made in Germany Double coated silk dome High power capable copper voice coil Gold plated aluminum housing Damped coupled chamber Wave diffuser Neodymium motor Gold plated screw terminal 1 pair / wooden box --------------------------------------------------- 2. GZPM Reference 80 (Midrange) GZPM Reference 80 80 mm / 3.15″ high end midrange speaker 120 Watts max 3.15″ high end midrange speaker with coated paper cone 80 mm / 3.15″ high end midrange speaker Made in Europe Coated and double pressed paper cone Conex spider Hand made basket with CNC milled parts Linearized motor India rubber surround Incl. protection grill Gold plated soldering terminal 1 pair / wooden box 3.GZMW Reference 180 180 mm high end midwoofer 150 Watts max 180 mm high end midrange speaker with coated paper cone 7″ high end midwoofer Made in Europe 25 mm / 1″ voice coil Conex spider Hand made basket with CNC milled parts Linearized motor Incl. protection grill Gold plated soldering terminal 1 pair / wooden box

GZRC 165.3SQ 165mm 2-Way Component Speaker-System Description 3-Way Sound Quality speaker system with variable crossover frequency, 3 ohm impedance and 25mm silk dome tweeter High quality 3-way SQ component system Klippel® optimized midwoofer with aluminum cone Nomex spider / rubber surround Copper cap for impedance linearizing Resonance free steel basket 3.15” SQ midrange with aluminum cone Neodymium motor / compound basket 1″ SQ silk dome tweeter with mounting accessories Vented neodymium motor 12 dB/oct. crossover with level adjustment (not for ACT version) 230 watt max. / 150 watt rms 3 Ohms Highlights Mehr Leistung am Verstärker / Radio durch 3 Ohm Technologie Variable Mittelton-Trennfrequenz (High/Low) Sehr hoher Wirkungsgrad (90dB) Großer Seidenkalottenhochtöner (25mm) für feinste Details und klaren Sound Anspruchsvoller 80mm Mitteltöner mit Neodym-Antrieb und Aluminiummembrane Leistungsstarker Tieftöner mit Aluminium-Membrane Technische Daten Durchmesser 165 mm Belastbarkeit (rms/max.) 150 / 230 Watt Impedanz 3 Ohm Wirkungsgrad 90 dB Frequenzgang 35 Hz – 25 kHz Hochtöner GZRT 25SQ Mitteltöner GZRM 80SQ Tieftonlautsprecher GZRK 16SQ Einbautiefe 68 mm Übergangsfrequenz Hochtöner 4600 Hz Übergangsfrequenz Mitelltöner 200 Hz

GZDSP 6-8X PRO 8-channel digital signal processor 8-channel DSP Digital signal processor with six channel high-level or RCA input, USB connection, digital and AUX input as well as auto-on function 8-channel digital signal processor High-level and line input Realtime setting 32 bit Cirrus Logic Prozessor Windows GUI software Separate 31 band equalizer for each channel Time delay Variable crossover Phase correction Automatic turn-on function for the high level input Model 8-channel digital signal processor High resolution compatible yes TOSLINK & Coaxial Input 24-bit / 12 -192 kHz AUX Anschluss 3.5 mm socket High-Level Audio Mix up to 6 channels Frequency Response 5 Hz – 20 kHz (-3 dB) Signal-to-Noise > 110 dB Eingangsempfindlichkeit 3 – 15 V (Hochpegel) Max. Output 4 V RMS, 4 V RMS Adapter for Apple® devices optional Remote Control optional Preset Memory 10, 10 Dimensions (b x l x h) 185 x 151 x 42 mm
