GZDSP 6-8X PRO 8-channel digital signal processor 8-channel DSP Digital signal processor with six channel high-level or RCA input, USB connection, digital and AUX input as well as auto-on function 8-channel digital signal processor High-level and line input Realtime setting 32 bit Cirrus Logic Prozessor Windows GUI software Separate 31 band equalizer for each channel Time delay Variable crossover Phase correction Automatic turn-on function for the high level input Model 8-channel digital signal processor High resolution compatible yes TOSLINK & Coaxial Input 24-bit / 12 -192 kHz AUX Anschluss 3.5 mm socket High-Level Audio Mix up to 6 channels Frequency Response 5 Hz – 20 kHz (-3 dB) Signal-to-Noise > 110 dB Eingangsempfindlichkeit 3 – 15 V (Hochpegel) Max. Output 4 V RMS, 4 V RMS Adapter for Apple® devices optional Remote Control optional Preset Memory 10, 10 Dimensions (b x l x h) 185 x 151 x 42 mm

GZPA 2SQ (Plutonium Series) 2-channel high performance SQ amplifier 1000 Watts 2-channel high end amplifier with integrated activ crossover, BIAS adjustment and high quality parts for dedicated music lovers High-End 2-channel SQ amplifier MOSFET technology Variable active crossover and bass boost, phase shift Variable BIAS setting High quality components Solid terminals Efficient heatsink with illuminated Ground Zero lettering Fulfilling High Resolution audio demands Model High-Performance SQ amplifier Channels 2 Output Power (@ 4Ω) 2x 175 Watts RMS Output Power (@ 2Ω) 2x 315 Watts RMS Output Power (@ 1Ω) 2x 500 Watts RMS max. Output 1200 Watts Frequency Response 10 Hz – 50 kHz HPF / LPF / BPF ● / ● / ● Bass Boost / Phase Shift ● / ● High-Level Input / Auto-on ○ / ○ Remote ○ BIAS Setting ● Linkmode ○ Dimensions (W x L x H) 222 x 420 x 60.5 mm / 8.74 x 16.54 x 2.38"

GZUW-12SQX Subwoofer Strong paper cone Dual voice coil 2 x 2 Ohm Audiophile POLYCOT spider Diameter 300 mm / 12" Voice coil 50 mm Runddraht / 2" Round wire Power Handling 600 WRMS Impedance 2 x 2 Ohm SPL 87,4 dB Fs 38.6 Hz

GZPA Reference 4XS Amplifier 4 Channel High End amplifier - 1000 Watt Max - High End audio-transistors, Elna and Mundorf MCap® capacitors - Burr Brown IC’’s for outstanding sound quality - Powerful shielded dual power supply, with extremely less interference - Variable bias setting to adjust the bias from normal class AB to nearly class A operation - The smoked plexiglas bottom with white LED illumination allowas to see the impressive PCB

MCR-805 Subwoofer ( BASSBOX ) 450W Maximum power output Built in 450W RMS Power Amplifier-Powerful and Undistorted low Frequency response. Weight : 6.2 Kgs. 8" Square Subwoofer Sealed endosure design-extended low frequency response. Subwoofer PHASE (0*/180*) Sub Crossover freauency adjustment (20Hz-150Hz). Wide range GAIN adjustment (0.4V-8V). Led Power indicator. Induded With Remote Controller In Subwoofer Square Shape. Auto Remote On When Speaker High Level Input. Dimesins (WxHxD) : 345 x 240 x 73 MM.
